Thomson AC added Air condoning to this Fountain Valley, CA home.

When we got the call for this add AC in Fountain Valley CA we couldn’t resist. We had been contracted to do a similar job for another unit in their home, and were ecstatic to go back and double their cooling capacity!


Project scope of work

Here’s a brief overview of the work performed:

  •  Install new 3 Ton, 13 SEER, 1-Stage, Amana Condenser (ASX130361) in approved location in attic
  • Install new 3 Ton Evaporator Coil to furnace
  • Install new Honeywell PRO Digital Programable Thermostat (TH611) in existing location
  • Install new 240v dedicated hi-voltage electrical circuit from existing electrical panel to condenser location
  • Install new 3/4″-3/8″ Copper Refrigerant Lines between condenser and evaporator coil
  • Install new lo-voltage control wiring between furnace and new A/C Condenser
  • Install new 2-piece paintable lineset cover/s to conceal refrigerant lines on exterior of home
  • Install Plastic Pad under new condenser to ensure proper drainage
  • Install Earthquake Brackets securing new condenser to plastic pad
  • Install Fusible Power Disconnect and Electrical Whip at new condenser
  • Install new Condensation Removal Pump and 3/8” Copper Primary Condensation Drain Line to terminate where downstairs drain line terminates
  • Seal and Insulate all exposed sheet metal and connection points
  • Pressurize refrigerant lines with nitrogen to test for leaks and remove moisture
  • Pull vacuum on refrigerant lines and evaporator coil to remove all non-condensibles
  • Charge system with R-410a Refrigerant using Superheat and Subcool calculations
  • Test equipment to ensure proper operation


Warranty information

Warranty? Yep. The customer’s equipment is backed by:

  • 10 Year Parts Warranty on Amana equipment Through Manufacturer
  • 2 Year Labor Warranty Through Thomson A/C


Project duration

Thomson AC’s Job Completion Timeline for This Job:

  • Equipment mounting and installation – 1 Day
  • Beautification and details – 1 Days


More information

More Information about Daikin and Thomson Air Conditioning

  • Thomson A/C California Contractor’s License Number – 959811
